Volt Alpine Electric Mountain Bike
Volt Alpine Electric Mountain Bike

Alpine
Electric Mountain Bike

New version coming in 2022

CHECK DELIVERY TIMES


-
+

Free UK Delivery to Local Assembly Point

We don't recommend child seats with this ebike





DISTANCE

Up to 60 or 80 Miles

FRAME

18"

WEIGHT

19.5 kg*

SPEED

15.5 mph

BATTERY

Lithium Ion 36v

YEARSWARRANTY

WARRANTY

2 Years*

The new generation of the Volt Alpine is designed to explore where there are no roads. Its stylish integrated battery design and powerful SpinTech™ motor offers high performance on a variety of on and off-road terrains and looks great whilst doing it.

The 250 Watt Super High Torque Bafang x SpinTech motor quipped with a bottom bracket torque sensor ensures this electric bicycle makes light work of hills and easy riding against strong winds but if you choose to ride without power assistance, the Alpine is a great ride with pedal power alone. You have a choice of 4 power modes allowing you to do as much or as little of the work as you wish.

The updated componentry takes the Alpine to a new level, geared with 120mm travel SR Suntour Tapered Suspension, 27.5” wheels with Maxxis Ikon tyres, Tektro Hydraulic Safety "Power Cut" brake levers and Shimano Alivio 8-speed gears, the Alpine guarantees you a fun and safe ride. The technology side of the bike is maintenance-free and very reliable, meaning you can take your electric bike in for routine servicing at any good quality bicycle shop throughout the UK and Europe.

The Volt Alpine comes as standard with a powerful integrated SpinTech™ Panasonic 36v Standard Lithium Battery (Up to 60 miles) with and optional 36v X-Large (Up to 80 miles) battery upgrade.







CategoryElectric Mountain Bike (E-MTB) Hardtail
LCD DisplayFive speed display with throttle system
FrameHigh Grade Reinforced Aluminium 6061 T6 Frame
Weight19.5 Kg Without Batteries / 22.7* Kg With Battery
Max Weight (rider+luggage)120 Kg
Frame Size18 Inches
Wheel Size27.5 Inches x 2.10
ChainKMC
WheelsAlexrim DP20 Double Wall Reinforced
TyresMaxxis IKON
SeatVelo Sport Comfort Saddle
Seat PostZoom
GearsShimano 8 Speed ALIVIO
BrakesTektro Hydraulic E-Comp
Torque SensorBafang BB
Front ForkSuspention SR Suntour X1 27.5 Tapered 120mm
HandlebarsZoom
Motor250 Watt Super High Torque SpinTech™ Motor
Max SpeedAssisted Motor Speed: 15.5 mph or 25 kmh
Location of MotorIn the rear wheel hub
Battery TypePanasonic Lithium battery
Battery Weight3,2 or 4,4kg
Power36v Standard 400Wh or 36v XL 630Wh
DistanceUp to 60 Standard or 80 miles XL*
Lifetime1000 charge-discharge cycles
Charge Time3 to 4 hours
Compact chargerProvided: for AC 100 V to 240 V - 50 or 60Hz



*The distances shown on our website are based on real tests under the following conditions:
Rider Weight: 11 Stone (Please note 11 Stone is the weight of the test rider and our e-bikes are capable of carrying riders well over this specified weight)
Controller Speed Setting: Low
Riding conditions: Warm summer day
Road conditions: Tarmacked good condition roads, quite flat terrain
Wind level: Low
Rider fitness level: Medium
Rider effort: Moderate

*If the end consumer's eBike is intended for commercial use ( e.g. rental company, messenger service), the warranty period lasts 12 months. Certain warranty exclusions may occur, please discuss with the manufacturer.

**All pictures shown are for illustration purpose only, actual product may vary due to product enhancement.
